AO Deflector
![[ Isomet ]<Br>Single/Dual Axis AOD (UV - Blue)](/thum_img/mjct/goods_img3/5415ebaac5b830525fdc70462384360e_water_4de0b559c44a49f5f544fca08f3bc282_c0_w300_h300.jpg)
 ','','/thum_img/mjct/goods_img3/5415ebaac5b830525fdc70462384360e_water_4de0b559c44a49f5f544fca08f3bc282_c0_w300_h300.jpg'))
Acousto-Optic Scanning and Deflection
•Fast scan speeds, no moving parts
•Small scan angles, but high repeatability
•Dual Axis capability
*모델명 클릭 시 데이터시트 확인가능
| Model | A/R Coating | Material | Rayleigh Res'n 1 2 |
Aperture (mm) HxW | Sweep BW (MHz) | Center Freq. (MHz) | Driver | Feature |
| D1393-T75S-8 | 400-500nm | TeO2 (S) | 110 | 8 | 14 | 75 | Here | |
| D1319-T220L-1p5 | 390-440nm | TeO2 | 70 | 1.5 x 3 | 100 | 220 | Here | |
| D1340-aQ120-5 | 343/355nm | Quartz | 25 | 5 | 30 | 120 | Here | |
| D1384-aQ120-9 | 343/355nm | Quartz | 50 | 9 x 12 | 40 | 120 | Here | |
| D1340-aQ130-5 | 280nm | Quartz | 25 | 5 | 30 | 130 | Here | |
| D1384-aQ170-7 | 343/355nm | Quartz | 100 | 7 x 12 | 70 | 170 | Here | |
| D1365-aQ180-4 | 266nm | Quartz | 35 | 4 | 60 | 180 | Here | |
| D1319-XY-T220L-2 | 405nm | TeO2 | 35 x 35 | 1.5 x 1.5 | 100 | 220 | Here | Dual axis |
| M1340-XY-aQ120-5 | 343/355nm | Quartz | 8 x 8 | 5 x 5 | 10 | 120 | Here | Low resolution XY |
| D1340-XY-aQ120-5 | 343/355nm | Quartz | 25 x 25 | 5 x 5 | 30 | 120 | Here | Dual axis |
| D1384-XY-aQ120-9 | 343/355nm | Quartz | 50 x 50 | 9 x 9 | 40 | 120 | Here | Dual axis |
| D1384-XY-aQ170-7 | 248nm | Quartz | 70 x 70 | 7 x 7 | 70 | 170 | Here | Dual axis |
