Laser power and energy meter, USB and RS232 PC interfaces, analog output, external trigger input, 10000 pps pyroelectric pulse repetition rate. 20 kHz and 625 kHz sampling modes available with Fast PowerMax-Pro sensors.

LabMax-Pro SSIM Features:

• Laser power and energy meter

• Compatible with PowerMax-Pro and PM Model thermopiles, LM model position-sensing thermopiles, LM-2 & OP-2 optical sensors, and EnergyMax DB-25 pyroelectric energy sensors

• High speed sampling for laser pulse analysis and energy integration

• Operation up to 10 kHz every pulse with pyroelectric sensors

• USB and RS-232 interfaces

• Windows PC application

• Direct host commands support OEM integration

• Windows 7 and 8 compatible (32 and 64-bit)

LabMax-Pro SSIM Applications:

• Production/QA

• Engineering & Scientific

• Commercial OEM Integration
