Fan cooled thermopile for measuring pulsed & CW lasers up to 200W with beam position measurement. Fan is configured for 110 VAC. Direct RS232 interface.

Key Features:

·      1W to 200W range (with Fan)

·      19 mm diameter active area

·      Beam position measurement

·      Spectrally flat broadband coating

·      0.25 to 10.6 µm spectral range

·      Fan-cooled

·      Fiber adapters available

·      Direct RS232 interface

·      ISO 17025 accredited

This PowerMax-RS LM-200 (110V) sensor is terminated in an RS232 cable that interfaces directly to a PC or industrial controller. A 110 VAC mains connection is required to power the fan.

A DB25 model (PN 1098440) is available.

SMA fiber adapter (PN 1098589) and FC/PC fiber adapter (PN 1098339) accessories are available when used with 1.035-40M Adapter Ring (PN 33-9432-000).

These unique position sensing thermopiles display the position of the incident beam on the sensor disk, in addition to measuring power. This information allows the user to safely and precisely align the sensor and the beam being measured. This is particularly useful for non-visible beams.
