SNG High Performances Green Microchip Series

For generating high peak power green pulses of a few hundred picoseconds, microchip lasers are economical, compact, and reliable. The 532nm pulses are produced by harmonic conversion from the IR systems, the same compact sealed package being used for either wavelength. Microchips are also easy to operate and service; controllers can be used with every laser head model and swapped within minutes while conserving constant performances. The SNG series are designed for high average power, delivering multi-kW peak power at repetition rates up to 70kHz.

APPLICATIONS

• Material processing - Cost effective marking solutions - Graphitization

• Instrumentation - Ranging - Differential absorption LIDAR - Super-continuum generation - Distributed temperature sensing - Raman spectroscopy

• Biophotonics - Nanosurgery - Protein cross-linking
