Shutter

추가 큰 이미지 보기

[ Radiant Dyes ]
Shutter & Controller

사양: Configuration : Digital

: Center position pulse length : 760 μs

: Minimum pulse length (typical) : 500 μs

: Maximum pulse length (typical) : 1000 μs

Data sheet: 다운로드

Catalog: 다운로드

브랜드: Radiant Dyes

견적문의

Shutter

We offer a wide range of Servo motors for lens mount with counter weight for titanium and compact shutters, Beam Blockers for titanium and compact shutters and different sizes of Servo Motors with various controller settings.

	Mini Servo Motor	Titanium Mini Servo Motor	Medium Speed Servo Motor	Compact Titanium Gear High Speed Servo Motor
Configuration	Digital
Dead band	-	-	8 μs	8 μs
Operating speed (at 4.8V)	0.055 s/60° without load	0.047 s/60° without load	0.052 s/60° without load	0.034 s/60° without load
Center position pulse length	760 μs	760 μs	760 μs	760 μs
Stall Torque (at 4.8V)	2.3 kg·cm	1.92 kg·cm	2.1 kg·cm	3.9 kg·cm
Maximum pulse frequency	333 Hz	333 - 560 Hz	560 Hz	560 Hz
Maximum pulse period	3000 μs	3000 μs	1786 μs	760 μs
Minimum pulse length (typical)	500 μs Channels A,B,C,D preprogrammed
Maximum pulse length (typical)	1000 μs Channels A,B,C,D preprogrammed

For more information please refer to Datasheet.

Controller

All channels are preprogrammed with factory default parameters. The time base values are changed to 3000 μs. These parameters are saved to the EEPROM and if there is a need for modification, the parameters have to be re-saved with the command save. To restore the saved parameters, the command restore has to be sent to the controller.
