Rotational mirror mount parameters

 Servo motor pulse length for 0°

 980 µs

 Servo motor pulse length for 180°

 500 µs

 Interpolation in range 0° ... 180°

 linear ±1%

 Recommended minimum speed (interpolation time)

 200 time steps

 Measured absolute precision in range 0° ...  180°

 ±1% (unidirectional)

 Measured unidirectional repeatability in range 0° ... 180°

 1°

 Postitioning resolution in range 0° ... 180°

 0.38° / µs

 Start-up position at power on

 vertical

 Hysteresis

 1.5°
